High Gripping Force
• Short Cycle Time
• Completely capsuled Mechanics
• User defined installation position
• Maintenance free up to 10 million movements
• Compact Design
• Modular Design
• multiple position monitoring through proximity
switch, optional
Drive pneumatic
max. Gripping Force (at 6 bar) * 625 N
max. Torque (at 6 bar) ** 50 Nm
Operating Air Pressure 2,5 to 6 bar
Open 0,25 s Cycle Time Close 0,25 s
Repeat Accuracy 0,1 mm
Energy Consumption per Cycle 1,2 liter
Operating Temperature -30 to +80°C
Mass 2,1 kg
Mx max. 40 Nm
My max. (Gripping) 50 Nm
Fz max. 10.000 N
Loading
Capacity* per
Finger with
Gripping Mass
and Acceleration Mz max. 30 Nm
